Address the critical challenge of freshwater scarcity in coastal and island regions with our advanced Land-Based 10TPD Seawater Desalination Plant. Engineered for reliability and high efficiency, this turnkey RO (Reverse Osmosis) system is specifically designed to convert seawater into pure, potable drinking water. Utilizing state-of-the-art membrane technology, the plant guarantees an impressive desalination rate of 98.5%, ensuring safe and clean water for residential communities, resorts, and remote coastal facilities where freshwater access is limited.
The fully automatic control system simplifies operation, allowing for hands-off management of the entire desalination process. The plant is built to handle high salinity input, featuring a robust construction with a feed water conductivity tolerance of ≥49000. It effectively reduces water hardness to ≤10 and maintains an outlet resistivity >0.7, meeting stringent drinking water standards. With a compact footprint of 1350x650x1850mm, this energy-efficient unit is the ideal solution for onshore applications, providing a sustainable and cost-effective answer to your water supply needs.
Key Features
-
HIGH DESALINATION RATE: Employs advanced RO membranes to achieve a 98.5% salt rejection rate, effectively removing impurities for pure drinking water.
-
FULLY AUTOMATIC OPERATION: Intelligent control panel allows for automatic start/stop and self-regulation, minimizing manual labor and operational errors.
-
OPTIMIZED FOR SEAWATER: Specifically designed to handle high TDS seawater with an inlet conductivity of ≥49000, producing safe water with ≤1400 outlet conductivity.
-
COMPACT & EFFICIENT: Produces 0.42 m³/h of purified water with a power consumption of only 8600W, offering an energy-saving solution for land-based use.
-
VERSATILE APPLICATIONS: Perfect for海岛 (islands), coastal areas, and industrial sites requiring a reliable freshwater supply.
Applications
-
Island Communities: Provides a sustainable source of drinking water for residents where freshwater resources are scarce.
-
Coastal Resorts & Hotels: Ensures a steady supply of high-quality water for guests and culinary use.
-
Remote Coastal Facilities: Ideal for military bases, research stations, and factories located near the sea.
-
Municipal Support: Augments local water supplies in coastal cities facing seasonal shortages.
Specifications
-
Model: JHH-SW-10
-
Technology: RO (Reverse Osmosis)
-
Capacity: 10 TPD (Tons Per Day) / 0.42 m³/h
-
Desalination Rate: 98.5%
-
Feed Water Source: Seawater
-
Feed Water Conductivity: ≥49000
-
Outlet Water Conductivity: ≤1400
-
Outlet Water Hardness: ≤10
-
Outlet Resistivity: >0.7
-
pH Range: 6.5-8.5
-
Working Temperature: 5-45℃
-
Working Pressure: >0.2 MPa
-
Recovery Rate: 32%
-
Power Supply: 220V/50Hz or 380V/60Hz
-
Rated Power: 8600W
-
Inlet Diameter: DN15
-
Dimensions: 1350 × 650 × 1850 mm
-
Weight: 300 kg
