The PHP Series Foam Proportioning and Mixing Device is engineered to deliver precise foam‑water mixtures for effective fire suppression in large‑scale industrial and commercial facilities. Built with a stainless steel storage tank and balanced valve system, it ensures durability, corrosion resistance, and long service life.
The device uses a mechanical pump to inject foam concentrate into the proportioner, automatically adjusting to water pressure and flow changes. This guarantees accurate mixing ratios (3% or 6%) and continuous foam supply during firefighting operations. The system supports multiple driving options, including electric motor, turbine, or diesel engine, providing flexibility and reliability.
Available in models ranging from PHP48 to PHP260, the device covers flow rates from 12 L/s to 260 L/s, making it suitable for diverse applications such as oil depots, transformer stations, boiler rooms, and ship engine compartments. Factory‑direct supply ensures competitive pricing, customization options, and professional support, making this system a cost‑effective solution for global customers seeking dependable foam fire suppression equipment.
Key Features
- DURABLE MATERIAL – Stainless steel tank construction ensures corrosion resistance and long service life.
- PRECISE MIXING – Balanced valve system maintains accurate foam‑water ratios under varying conditions.
- MULTIPLE MODELS – Flow rates from 12 L/s to 260 L/s for different applications.
- EASY OPERATION – Supports electric, turbine, or diesel drive options for flexible use.
- CERTIFIED QUALITY – Complies with national fire safety standards and industrial requirements.
Applications
- Chemical plants and petroleum storage facilities
- Airports and aircraft hangars
- Transformer stations and boiler rooms
- Ship engine compartments and marine engineering
- Industrial warehouses and automotive garages
Specifications
| Model | Pressure Range (MPa) | Flow Range (L/s) | Mixing Ratio | Pressure Loss (MPa) | Inlet/Outlet Diameter |
|---|---|---|---|---|---|
| PHP48 | 0.6–1.2 | 12–48 | 3% or 6% | <0.15 | DN100 |
| PHP64 | 0.6–1.2 | 12–64 | 3% or 6% | <0.15 | DN150 |
| PHP100 | 0.6–1.2 | 24–100 | 3% or 6% | <0.15 | DN150 |
| PHP160 | 0.6–1.2 | 36–160 | 3% or 6% | <0.15 | DN200 |
| PHP260 | 0.6–1.2 | 60–260 | 3% or 6% | <0.15 | DN250 |
Extra Sections
Functions
- Provides continuous foam‑water mixture for effective fire suppression
- Automatically adjusts to water pressure and flow changes
Advantages
- Long service life with minimal maintenance
- Flexible drive options for diverse environments
- Factory‑direct supply ensures cost savings
